r lgy co RTL9201R-CG altek tial fo chno USB 3.2 GEN1 to SATA GEN3 BRIDGE Re fiden ke te DATASHEET n a (CONFIDENTIAL: Development Partners Only) Co hu Rev. 1.0 p 31 March 2022 e Track ID: JATR-8275-15 de Realtek Semiconductor Corp. n No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan e Tel.: +886-3-578-0211. Fax: +886-3-577-6047 Shenzh .realtek. RTL9201R Datasheet 1. General Description The Realtek RTL9201R-CG (hereafter referred to as the RTL9201R) USB (Universal Serial Bus) to SSD (Solid-State Disk) bridge bines a USB device with a SATA bus controller, and embedded memory. The RTL9201R supports USB 3.2 GEN1 (Super Speed). It is patible with USB High Speed and Full Speed. It can operate normally using auxiliary power. The Mass Storage transaction supports both Bulk Only Transfer (BOT) and USB Attached SCSI Protocol (UASP). For USB, it provides up to 5Gbps bandwidth. The RTL9201R supports SATA Gen3. For SATA, it provides up to 6Gbps bandwidth. It has full o backward patibility for SATA Gen2/Gen1. To reduce power consumption, the RTL9201R supports c link power management (Partial Mode/Slumber Mode/DEVSLP Mode). r lgy The RTL9201R is suitable for multiple market segments and emerging applications, such as desktop, mobile, workstation, server, munications platforms, and embedded applications. ltek l fo no The RTL9201R supports security of SHA256 (Secure Hash Algorithm 256 bits), CRC32 (Cyclic Redundancy Check 32 bits) and LBA (Logical Block Address) protection for security requirements. Shenzhen Cd Roeeneafpidheunatikae tech USB3.2Gen1to SATAGen3Bridge Track ID: JATR-8275-15 Rev. 1.0 RTL9201R Datasheet 2. Features General - USB to SATA SSD bridge - Integrated with Type-C connector - Supports External Serial Peripheral Interface (SPI) Flash - Supports full mand set of SATA SCSI Translation (e.g., UNMAP, Security protocol in/out …) - Supports Security Send and Receive - Supports SMART/Health information - Supports...
