RT5035D Overview
Description
The RT5035C/D is a highly-integrated DSC Power Management IC that contains 7CH switching DC-DC converters and two generic LDOs, one keep-alive low-quiescent LDO for RTC, one load switch with soft-start control and current limit, a switch with reverse leakage prevention for backup battery, and a Real-Time-Clock (RTC) including time counter and 32768Hz oscillator. The DC-DC converters are one low-voltage Step-Up operated in either Async-PFM or Sync-PWM, one current mode Sync Step-Up/Down (Buck-Boost), four Sync Step-Down, and one Asyn Step-Up for WLED driver.
Key Features
- CH1 Sync Step-Up in PWM Mode or Async Step-Up in Pulse Frequency Mode
- CH2 Current Mode Sync Step-Up/Down
- CH3/CH4/CH5 Current Mode Sync Step-Down
- SW4 Load Switch with Soft-Start Inrush Control And Current Limit
- CH6 Generic Low Voltage LDO for CMOS Sensor
