RT6336
RT6336 is manufactured by Richtek.
23V, 6A Synchronous Buck Converter with 3.3V/5V LDO
1 General Description
The RT6336 family consists of high-efficiency synchronous buck converters with pseudo constant switching frequency 500kHz, delivering up to 6A output current. The RT6336A/RT6336B and RT6336AH/RT6336BH operate from 4.5V to 23V input voltage. The output voltage of the RT6336A/RT6336AH is programmed between 0.6V to 5.5V and RT6336B/RT6336BH is fixed to 3.3V output voltage. The input voltage of RT6336C/RT6336CH ranges from 5.2V to 23V and the output voltage of RT6336C/RT6336CH is fixed to 5.1V.
The RT6336 family adopts Advanced Constant OnTime (ACOT® ) control architecture that provides ultrafast transient...
