DA228U
Features
1) Ultra small mold type. (UMD3) 2) High reliability.
- Construction Silicon epitaxial planar
- Dimensions (Unit : mm)
2.0±0.2 0.3±0.1 各Eリa同cーh寸ドl法eとadもhas same dimension 0.15±0.05 (3)
(2)
(1)
（0.65） （0.65） 1.3±0.1
0～0.1
0.7±0.1 0.9±0.1
(1)D2:C (2)D1:A
ROHM : UMD3 JEDEC : SOT-323
(3)D1:C D2:A
JEITA : SC-70 dot (year week factory)
- Taping specifications (Unit : mm)
4.0±0.1
2.0±0.05
φ1.55±0.05
1.25±0.1 2.1±0.1 0.1Min
0.9MIN. 1.6
- Land size figure (Unit : mm) 1.3
0.8MIN UMD3
- Structure
0.3±0.1
1.75±0.1
8.0±0.2
3.5±0.05
2.4±0.1
2.4±0.1
5.5±0.2
0～0.1
- Absolute maximum ratings (Ta=25°C)
Parameter
Symbol
Reverse voltage (repetitive peak) VRM
Reverse voltage (DC)
Forward current...
