MS5194T Datasheet Low Noise Low Power Dissipation ADC

Manufacturer: Ruimeng

📥 Download Datasheet

Datasheet Details

Part number MS5194T
Manufacturer Ruimeng
File Size 555.07 KB
Description Low Noise Low Power Dissipation ADC
Download MS5194T Download (PDF)

General Description

The MS5194T/MS5195T is a 24-bit/16-bit ADC featured by low power dissipation, low noise, six differential input channels and it is suitable for high-precision measurement application.

The MS5194T/MS5195T integrates low noise input buffer, low noise instrumentation amplifier, internal bandgap reference with high precision, low noise and low drift, and it also could adopt external differential reference voltage.

In addition, the MS5194T/MS5195T also integrates programmable excitation current source, burnout current source and bias voltage generator.

Overview

MS5194T/MS5195T Low Noise, Low Power Dissipation, 24/16-Bit ∑-Δ ADC.

Key Features

  • RMS Noise: MS5194T: 40nV@16.7Hz.
  • Power Dissipation: 400μA(typ).
  • Integrated Low Noise, Programmable Gain Instrumentation Amplifier.
  • Integrated Voltage Reference with Low Temperature Drift : 5ppm/°C.
  • Update Rate: 4.17Hz to 470Hz.
  • Integrated 50Hz/60Hz Rejection Filter.
  • Integrated Programmable Current Source.
  • Integrated Internal Clock Oscillator.
  • Integrated Internal Burnout Current, Excitation Current.
  • Integrated Bias Voltage Generator.
  • Power S.
