LB1216 Overview
Ordering number:EN 1042F Monolithic Digital IC LB1211 Series General-Purpose Transistor Array The LB1211 series are general-purpose transistor arrays containing 7 channels (5 channels : They are especially suited for driving LEDs, lamps, small-sized relays, etc. The transistors can be standardized.
LB1216 Key Features
- mon-emitter 7 channels
- mon-collector 7 channels
- Independent 5 channels
- Built-in base current limiting resistors
- Built-in Zener diodes for level shift
- Capable of being direct driven with TTL, CMOS, PMOS, etc
- Wide operating voltage and temperature ranges
