SY20213B Description
Features The SY20213B is a high efficiency 3MHz synchronous step down DC/DC regulator IC capable of delivering up to 0.6A output current. It can operate in PFM or CCM mode during light load programed by MODE pin. It can operate over a wide input voltage range from 1.85V to 5.5V and integrate main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss.
SY20213B Key Features
- 1.85~5.5V input voltage range
- 3MHz switching frequency
- 40uA low quiescent current
- Low RDS(ON) for internal switches (PFET/NFET)
- Fixed 100us soft-start time
- PFM/CCM operation mode during light load
- Hic-cup mode protection for hard short condition
- RoHS pliant and Halogen Free
- pact package: DFN1.45x1-6
