SY26003
Description
The SY26003 is a high efficiency 2.4MHz synchronous step down DC/DC regulator which is capable of delivering up to 3A output currents. It can operate over a wide input voltage range from 2.5V to 6V and integrates main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss.
Key Features
- 2.5~6.0V Input Voltage Range
- 23μA Low Quiescent Current
- Low RDS(ON) for Internal Switches (Top/Bottom) 31mΩ /23mΩ
- Instant PWM Control Achieve Ultra Fast Dynamic Response
- Internal Soft-start Limits the Inrush Current
- 100% Drop Out Operation
- Output Auto Discharge Function
- Hiccup Mode for Short Circuit Protection
- RoHS compliant and Halogen Free
- pact Package: DFN2×2-7
