1SS352
1SS352 is FAST SWITCHING DIODE manufactured by Slkor Micro Semicon.
FAST SWITCHING DIODE Features
- Small Package
- Low forward voltage
- Fast reverse recovery time
- Small total capacitance
SOD-323 top view
Schematic diagram
- C1 +
Marking and pin assignment
Maximum Ratings and Electrical Characteristics, Single Diode @Ta=25℃
Symbol
VRM VR IO IFM IFSM PD RΘJA TJ,Tstg
Parameter
Non-Repetitive Peak Reverse Voltage Reverse Voltage Average forward current Forward Continuous Current Non-repetitive Peak Forward Surge Current@t= 10ms Power Dissipation Thermal Resistance from Junction to Ambient Operation Junction and Storage Temperature Range
Value
85 80 100 200 1 200 625 -55~+150
Unit
V V m A m A A m W °C/W °C
Electrical Ratings @Ta=25℃
Symbol
Parameter
IR1
Reverse current
IR2
VF1
VF2
Forward voltage
VF3
Ctot
Capacitance Between Terminals...
