SPLC782A Overview
Description
The SPLC782A, a dot-matrix LCD controller and driver, is a - Provide connecting to 4-bit or 8-bit MPU low-power CMOS integrated circuit. The SPLC782A is capable - Direct driver for LCD: 16 COMs x 80 SEGs of connecting with MPU for LCD application and easily to be used - 80-channel Bi-Direction segment driver for designing the low-cost products.
Key Features
- Character generator ROM: 10880 bits tia ly ─ Character font 5 x 8 dots: 192 characters n n ─ Character font 5 x 10 dots: 64 characters
- 4 type CGROM mode, Max. 256 characters can be used. e O
- LCD type-A, type-B waveform can be selected
- Built-in power on automatic reset circuit
- Built-in oscillator circuit
