Datasheet Summary
XC9287/XC9288 Series
ETR05088-002b
HiSAT-COT® Control, 1.5A Synchronous Step-Down DC/DC Converter
☆Green Operation patible
- GENERAL DESCRIPTION
The XC9287/XC9288 series are 1.5A synchronous step-down DC/DC converters with a built-in P-channel driver FET and Nchannel driver FET.
The Output voltage is internally set in a range from 0.8V to 3.6V increments of 0.05V. Only an inductor and two capacitors were connected externally.
Oscillation frequency is set to 1.2MHz or 3.0MHz can be selected for suiting to your particular application. HiSAT-COT is a proprietary high-speed transient response technology for DC/DC converter which was minimized output voltage during load fluctuations. It is...
