AO4948
AO4948 is Dual N-Channel Enhancement Mode Field Effect Transistor manufactured by VBsemi.
AO4948-VB
AO4948-VB Datasheet Dual N-Channel Enhancement Mode Field Effect Transistor with Schottky Diode
.VBsemi.
PRODUCT SUMMARY
VDS (V)
RDS(on) (Ω)
0.008 at VGS = 10 V 30
0.012 at VGS = 4.5 V
ID (A) 8 6.8
Qg (Typ.) 15 nC
S2/A 1 8 D2/K G2 2 7 D2/K S1 3 6 D1 G1 4 5 D1
SOIC-8
Features
- Halogen-free According to IEC 61249-2-21
Definition
- Trench Power MOSFET
- 100 % UIS Tested
- 100 % Rg Tested
- pliant to RoHS Directive 2002/95/EC
APPLICATIONS
- Set Top Box
- Low Current DC/DC
D2
D1
G2
G1
S2
S1...
