AO6810
AO6810 is 20V Dual N-Channel MOSFET manufactured by VBsemi.
FEATURES
- Halogen-free According to IEC 61249-2-21 Definition
- Trench Power MOSFET
- 100 % Rg Tested
- pliant to Ro HS Directive 2002/95/EC
D1
D2
G1
G2
S1 N-Channel MOSFET
S2 N-Channel MOSFET
ABSOLUTE MAXIMUM RATINGS TA = 25 °C, unless otherwise noted
Parameter
Symbol
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current (TJ = 150 °C) Pulsed Drain Current
TC = 25 °C TC = 70 °C TA = 25 °C TA = 70 °C
Continuous Source-Drain Diode Current
TC = 25 °C TA = 25 °C
TC = 25 °C
Maximum Power Dissipation
TC = 70 °C TA = 25 °C
TA = 70 °C
Operating Junction and Storage Temperature Range
Soldering Remendations (Peak Temperature)d, e
VDS VGS ID
IDM IS
TJ, Tstg
Limit
20 ± 12 6.0 4.0 3.5b, c 2.8b, c 18 1.17 0.95b, c 1.6
1.0 1.14b, c 0.73b, c
- 55 to 150
THERMAL RESISTANCE RATINGS
Parameter
Maximum Junction-to-Ambientb, d t ≤5 s
Maximum Junction-to-Foot
Steady...
