W83782D
Description
W83782D is an evolving version of W83782D --- Winbond's most popular hardware status monitoring IC.
Key Features
- 2.1 Monitoring Items
- 3 thermal inputs from remote thermistors or 2N3904 NPN-type transistors or PentiumTM II (Deschutes) thermal diode output
- 9 voltage inputs
- typical for Vcore, +3.3V, +12V, -12V, +5V, -5V, +5V Vsb, Vbat, and one reserved
- 3 fan speed monitoring inputs
- Case open detection input
- WATCHDOG parison of all monitored values
- Programmable hysteresis and setting points (alarm thresholds) for all monitored items 2.2 Actions Enabling
- Beep tone warning
- 4 PWM (pulse width modulation) outputs for fan speed control (3 are MUX optional)
