WF0128BTYAA4DNN0
WF0128BTYAA4DNN0 is TFT Display manufactured by WINSTAR Display.
Winstar Display Co., LTD
華凌光電股份有限公司
WEB: https://.winstar..tw E-mail: sales@winstar..tw
SPECIFICATION
MODULE NO.: WF0128BTYAA4DNN0#
General Specifications
Item
Dimension
Unit
Size
1.28 inch
Dot Matrix
240 x RGB x 240 (TFT) dots
Module dimension
35.60 x 37.74 x 1.56 mm
Active area
32.40 x 32.40 mm
Dot pitch
0.043 x 0.135 mm
LCD type
TFT, Normally Black, Transmissive
Viewing Angle
80/80/80/80
TFT Interface
Backlight Type
LED ,Normally White
Driver IC
GC9A01
Touch Panel
Without Touch...
