MBR0540
MBR0540 is Schottky Rectifier manufactured by Yangjie Electronic.
- Part of the MBR0520 comparator family.
- Part of the MBR0520 comparator family.
Features
- VR 20V/30V/40V
- IFAV 0.5A
- For Surface Voltage and Extremely Low Thermal Resisitance
- Moisture Sensitivity Level 1
Mechanical Data
- Package: SOD123
- Terminals: Tin plated leads, solderable per
J-STD-002 and JESD22-B102
- Polarity: Cathode line denotes the cathode end
- Marking:
MBR0520
R2
MBR0530
R3
R4
- Maximum Ratings (Ta=25℃ Unless otherwise specified）
PARAMETER
SYMBOL UNIT
Conditions
VALUE
Maximum Recurrent Peak Reverse Voltage
VRRM
DC Blocking Voltage
IR=0.2m A
Peak forward surge current Average forward current Power dissipation Thermal Resistance from junction to ambient(Note) Maximum junction temperature Storage temperature range
IFSM IFAV Ptot RθJA Tj Tstg
A A m W ℃/W ℃ ℃
8.3ms, half sine
MBR0520
MBR0530
MBR0520
MBR0530
-55 to +125
-55 to...
