Datasheet Summary
60 AMP MINIATURE POWER RELAY
Features
- Single pole / normally open miniature power relay
- 60 Amp switching capability
- High dielectric strength of 4.5 kVRMS
- 10 kV surge withstand voltage
- pact size with less than 484 mm² (0.75 sq.in) of board space required
- Flux proof RTII and wash tight RTIII versions available
- TÜV, UL / CUR and CQC approvals
CONTACTS
Arrangement Ratings (max.) switched power switched current switched voltage Approved ratings UL/CUR/TÜV/CQC
Contact material Contact gap Contact resistance initial typical
SPST-NO (1 Form A)
(resistive load) 28800 VA 60 A 480 VAC
60 A at 277 VAC, resistive, 60°C, 1k cycles 1) 50 A at 480 VAC, resistive, 85°C, 6k cycles...
