AZ7707
FEATURES
- Ordering options from 3A to 10A
- 4 k V dielectric strength available
- 200m W and 450m W coil options
- Epoxy sealed version available
- UL Class F insulation (155°C) available
- TÜV, UL / CUR and CQC approvals (pending)
CONTACTS
Arrangement Ratings (max.)
SPST (1 Form A), SPDT (1 Form C) (resistive load)
3A versions switched power switched current switched voltage
90 W or 750 VA 3A 30 VDC- or 400 VAC
5A version switched power switched current switched voltage
150 W or 1250 VA 5A 30 VDC- or 400 VAC
High capacity switched power switched current switched voltage
150 W or 2500 VA 10 A 30 VDC- or 400 VAC
Rated Loads
- Note: If switching voltage is greater than 30 VDC, special precautions must be taken. Please contact the factory.
AZ7707, form C, 0.45W
3 A at 250 VAC, Gen.Pur., 100k cycles, 85°C 1) 3 A at 30 VDC, Res., 100k cycles, 85°C 1)
AZ7707, form A, 0.2 W
3 A at 277 VAC, Res., 50k cycles, 85°C 2) 3 A at 30 VDC, Res., 50k cycles, 85°C 2)
AZ7707, form A, 0.45...
