MSPM0G3507
Overview
- Core - Arm® 32-bit Cortex®-M0+ CPU with memory protection unit, frequency up to 80MHz
- Operating characteristics - Extended temperature: -40°C up to 125°C - Wide supply voltage range: 1.62V to 3.6V
- Memories - Up to 128KB of flash memory with error correction code (ECC) - Up to 32KB of SRAM with hardware parity
- High-performance analog peripherals - Two simultaneous sampling 12-bit 4Msps analog-to-digital converters (ADCs) with up to 17 external channels
- 14-bit effective resolution at 250ksps with hardware averaging - One 12-bit 1Msps digital-to-analog converter with integrated output buffer (DAC) - Two zero-drift zero-crossover chopper op-amps (OPA)
- 0.5µV/°C drift with chopping
- Integrated programmable gain stage, up to 32x - One general-purpose amplifier (GPAMP) - Three high-speed comparators (COMP) with 8- bit reference DACs
- 32ns propagation delay in high-speed mode
- Support low-power mode operation down to 1µA - Programmable analog connections between ADC, OPAs, GPAMP, COMP and DAC - Configurable 1.4V or 2.5V internal shared voltage reference (VREF) - Integrated temperature sensor
- Optimized low-power modes - RUN: 101µA/MHz (CoreMark) - SLEEP: 40µA/MHz - STOP: 190µA at 4MHz - STANDBY: 1.5µA with 32KHz LFXT, RTC with
