SBAW56L
SBAW56L is Dual Switching Diode Common Anode manufactured by onsemi.
Dual Switching Diode mon Anode
BAW56L, SBAW56L
Features
- S Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements; AEC- Q101 Qualified and PPAP Capable
- These Devices are Pb- Free, Halogen Free/BFR Free and are Ro HS pliant
MAXIMUM RATINGS (EACH DIODE)
Rating
Symbol Value
Unit
Reverse Voltage
Forward Current
Forward Surge Current (60 Hz @ 1 cycle)
200 m A
IFSM
Non- Repetitive Peak Forward Current
IFSM
A t = 1 ms (Note 3)
Repetitive Peak Forward Current
IFRM
500 m A
Pulse Wave = 1 sec, Duty Cycle = 66%
ESD Rating:
Human Body Model Machine Model Charged Device Model
Class 3A Class M4 Class C3
THERMAL CHARACTERISTICS
Characteristic
Symbol
Max
Unit...
