PE42451 - High-Isolation SP5T RF Switch

General Description

The PE42451 is a HaRP™-enhanced absorptive SP5T RF switch developed on the UltraCMOS® process technology.

This general-purpose switch is comprised of five symmetric RF ports and has extremely high isolation.

Key Features

  • HaRP™-enhanced UltraCMOS® device Five symmetric, absorptive RF ports High Isolation: 68 dB at 450 MHz 62 dB at 900 MHz 55 dB at 2100 MHz 53 dB at 2600 MHz 50 dB at 4000 MHz 43 dB at 5000 MHz IIP2: 95 dBm IIP3: 58 dBm High ESD tolerance: 3500 V HBM Optional external Vss control (VssEXT) 3-pin CMOS logic control No blocking capacitors required Packaging: Small RoHS-compliant 24-lead 4 × 4 mm QFN Figure 1. PE42451 functional diagram Product.

📥 Download Datasheet

Datasheet Details

Part number PE42451
Manufacturer pSemi
File Size 1.78 MB
Description High-Isolation SP5T RF Switch
Datasheet download datasheet PE42451 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
PE42451 High-Isolation RF Switch Peregrine Semiconductor
PE4245 SPDT UltraCMOS RF Switch Peregrine Semiconductor
PE42452 SP5T RF Switch Peregrine Semiconductor
PE4240 SPST UltraCMOS CATV Switch DC Peregrine Semiconductor
PE4241 SPDT UltraCMOS RF Switch Peregrine Semiconductor

Other Datasheets by pSemi

Part Number Description
PE42452 SP5T RF Switch
PE42420 SPDT RF Switch
PE42421 SPDT RF Switch
PE42427 SPDT RF Switch
PE42440 SP4T RF Switch

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
PE42451 Document category: Product Specification UltraCMOS® High-Isolation SP5T RF Switch, 450-5000 MHz Features HaRP™-enhanced UltraCMOS® device Five symmetric, absorptive RF ports High Isolation: 68 dB at 450 MHz 62 dB at 900 MHz 55 dB at 2100 MHz 53 dB at 2600 MHz 50 dB at 4000 MHz 43 dB at 5000 MHz IIP2: 95 dBm IIP3: 58 dBm High ESD tolerance: 3500 V HBM Optional external Vss control (VssEXT) 3-pin CMOS logic control No blocking capacitors required Packaging: Small RoHS-compliant 24-lead 4 × 4 mm QFN Figure 1. PE42451 functional diagram Product description The PE42451 is a HaRP™-enhanced absorptive SP5T RF switch developed on the UltraCMOS® process technology. This general-purpose switch is comprised of five symmetric RF ports and has extremely high isolation.
