AI329 - 1/3 inch CCD Image Sensor

A1 PROs

Datasheet Details

The Ai329 is a 290K pixels CCD area sensor for CCIR 1/3inch video cameras.

a strong anti-blooming and electronic shutter with variable charge-storage time. Feature -. Micro Lens for high sensitivity -. Image-lag is negligible and excellent blooming suppression is performed. -. TTL level(5V) operation on HCCD & RG electrodes. -. 16 pin plastic-DIP. -. Variable electronic shutter of 1/50 to 1/100,000 sec. -. High sensitivity and low smear. Pin Configuration V4 1 V3 2 V2 3 V1 4 GND 5 VGG 6 VSS 7 VOUT 8 16 H 2 15 H 1 14 NC 13 VRG 12 VP 11 VSUB 10 GND 9 VDD 16 Pin Plast.
