AI325 - 1/3 inch CCD Image Sensor

A1 PROs

Datasheet Details

The Ai325 is a 250K pixels CCD area sensor for EIA 1/3inch video cameras.

a strong anti-blooming and electronic shutter with variable charge-storage time. Feature -. Micro Lens for high sensitivity -. Image-lag is negligible and excellent blooming suppression is performed. -. TTL level(5V) operation on HCCD & RG electrodes. -. 16 pin plastic-DIP. -. Variable electronic shutter of 1/60 to 1/100,000 sec. -. High sensitivity and low smear. Pin Configuration V.
4õ 1 V.
3õ 2 V.
2õ 3 V.
1õ 4 GND 5 VGG 6 VSS 7 VOUT 8 16 H.
2õ 15 H.
1õ 14 NC 13 VRG.
