LPS 60
60 Watts
LPS 60 Series
Total Power Input Voltages # of Outputs
w wS P E C I A L
• • • • • • • • •
at .D w
aS
e e h
U 4 t
m o .c
60 - 80 Watts
85 - 264 VAC 120 - 370 VDC Single
F E AT U R E S
Universal input High efficiency Remote sense Built-in EMI filter Low output ripple Adjustable output Overvoltage protection Overload protection Enclosure kit available (see page 56 or PowerFAX Doc. no 1025)
E L E C T R I C A L S P E C I F I C AT I O N S Input
E N V I R O N M E N TA L
Operating temperature: 0° to 50°C ambient derate each output at 2.5% per degree from 50° to 70°C Electromagnetic susceptibility: designed to meet IEC 801, -2, -3, -4, -5, -6, Level 3 Humidity: Operating; non-condensing 5% to 95%
Input range ........................... 85-264 VAC 120-370 VDC Frequency ..
