AT1846S - SINGLE CHIP TRANSCEIVER

AT1846S Description

AT1846S/AT1846SD SINGLE CHIP TRANSCEIVER FOR WALKIE TALKIE 1.General .
The AT1846S is a highly integrated single-chip transceiver for Walkie Talkie applications.

AT1846S Features

* CMOS single-chip fully-integrated transceiver
* Fully integrated frequency synthesizer and VCO
* Support worldwide frequency band
* AT1846S :134MHz ~ 174MHz 200MHz ~ 260MHz 400MHz ~ 520MHz
* AT1846SD :320MHz ~ 400MHz
* 12.5KHz, 25KHz channels
* Support multiple XTAL cl

AT1846S Applications

* It totally realizes the translation from RF carrier to voice in the RX path and from voice to RF carrier in the TX path, requiring only one micro controller. The AT1846S has a powerful digital signal processor, which makes it have optimum voice quality, flexible function options, and robust perform

📥 Download Datasheet

Preview of AT1846S PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
AT1846S
Manufacturer
AUCTUS
File Size
511.44 KB
Datasheet
AT1846S-AUCTUS.pdf
Description
SINGLE CHIP TRANSCEIVER
