AT1846SD, AT1846S - SINGLE CHIP TRANSCEIVER

AT1846SD Description

AT1846S/AT1846SD SINGLE CHIP TRANSCEIVER FOR WALKIE TALKIE 1.General .
The AT1846S is a highly integrated single-chip transceiver for Walkie Talkie applications.

AT1846SD Features

* CMOS single-chip fully-integrated transceiver
* Fully integrated frequency synthesizer and VCO
* Support worldwide frequency band
* AT1846S :134MHz ~ 174MHz 200MHz ~ 260MHz 400MHz ~ 520MHz
* AT1846SD :320MHz ~ 400MHz
* 12.5KHz, 25KHz channels
* Support multiple XTAL cl

AT1846SD Applications

* It totally realizes the translation from RF carrier to voice in the RX path and from voice to RF carrier in the TX path, requiring only one micro controller. The AT1846S has a powerful digital signal processor, which makes it have optimum voice quality, flexible function options, and robust perform

📥 Download Datasheet

AT1846SD Datasheet Preview — This datasheet PDF includes multiple part numbers: AT1846SD, AT1846S. Please refer to the document for exact specifications by model.

Datasheet Details

Part number: AT1846SD, AT1846S
Manufacturer: AUCTUS
File Size: 511.44 KB
Datasheet: AT1846S-AUCTUS.pdf
Description: SINGLE CHIP TRANSCEIVER
Note: This datasheet PDF includes multiple part numbers: AT1846SD, AT1846S.
Please refer to the document for exact specifications by model.
