AP30N30W N-CHANNEL ENHANCEMENT MODE POWER MOSFET

AP30N30W Pb Free Plating Product Advanced Power Electronics Corp.▼ 100% Avalanche Test ▼ Simple Drive Requirement ▼ Lower On-resistance ▼ RoHS Compl.
AP30N30 from APEC provide the designer with the best combination of fast switching , low on-resistance and cost-effectiveness .

AP30N30W_AdvancedPowerElectronics.pdf

AP30N30W Datasheet Preview — Preview of AP30N30W PDF

Datasheet Details

Part number:

AP30N30W

Manufacturer:

Advanced Power Electronics

File Size:

141.39 KB

Description:

N-CHANNEL ENHANCEMENT MODE POWER MOSFET

Applications

* with higher power level preclusion than TO-220 device. G D S TO-3P Absolute Maximum Ratings Symbol VDS VGS ID@TC=25℃ ID@TC=100℃ IDM PD@TC=25℃ EAS IAR TSTG TJ Drain-Source Voltage Gate-Source Voltage www. DataSheet4U. com Parameter Rating 250 ±30 36 23 144 208 1.7 3 Units V V A A A W W/℃ mJ A ℃ ℃
