* Power MOS 7® MOSFETs - Low RDSon - Low input and Miller capacitance - Low gate charge - Avalanche energy rated - Very rugged
* Kelvin source for easy drive
* Very low stray inductance - Symmetrical design - Lead frames for power connections
* Internal thermistor for temperature mon
APTM20DUM10T Datasheet (328.90 KB)
APTM20DUM10T
Advanced Power Technology
328.90 KB
Mosfet power module.
APTM20DUM10T Dual common source MOSFET Power Module VDSS = 200V RDSon = 10mW max @ Tj = 25°C ID = 175A @ Tc = 25°C Application AC Switches .
