AOZ2387QI Datasheet - Alpha & Omega Semiconductors

25V/20A Synchronous Regulator

AOZ2387QI Features

* multiple protection functions such as VCC under-voltage lockout, cycle-by-cycle current limit, output over-voltage protection, short-circuit protection, and thermal shutdown. Features

* Wide input voltage range - 5.5 V to 25 V if internal LDO supply VCC - 4 V to 25 V if external VCC supply

AOZ2387QI General Description

The AOZ2387QI is a high-efficiency, easy-to-use DC/DC synchronous buck regulator that operates up to 25 V. The device is capable of supplying 20 A of continuous output current with an output voltage adjustable down to 0.6 V (±1.0%). The AOZ2387QI integrates an internal linear regulator to generate 5.

AOZ2387QI Datasheet (3.30 MB)

AOZ2387QI Datasheet Preview — Preview of AOZ2387QI PDF

Datasheet Details

Part number:

AOZ2387QI

Manufacturer:

Alpha & Omega Semiconductors

File Size:

3.30 MB

Description:

25v/20a synchronous regulator.
