AD5300 Datasheet, Dac, Analog Devices

AD5300 Features

• Dac Single 8-Bit DAC 6-Lead SOT-23 and 8-Lead MSOP Packages Micropower Operation: 140 μA @ 5 V Power-Down to 200 nA @ 5 V, 50 nA @ 3 V 2.7 V to 5.5 V Power Supply Guaranteed Monotonic by De

PDF File Details

Part number:

AD5300

Manufacturer:

Analog Devices ↗

File Size:

237.79kb

Download:

📄 Datasheet

Description:

8-bit dac. The AD5300 is a single, 8-bit buffered voltage output DAC that operates from a single 2.7 V to 5.5 V supply, consuming 115 μA at 3 V.

AD5300 Application

• Applications APPLICATIONS Portable Battery-Powered Instruments Digital Gain and Offset Adjustment Programmable Voltage and Current Sources Programma
