AD8180 Datasheet, Multiplexers, Analog Devices

AD8180 Features

• Multiplexers Fully Buffered Inputs and Outputs Fast Channel Switching: 10 ns High Speed > 750 MHz Bandwidth (
    –3 dB) 750 V/␮s Slew Rate Fast Settling Time of 14 ns to 0.1% Low Power:

PDF File Details

Part number:

AD8180

Manufacturer:

Analog Devices ↗

File Size:

255.01kb

Download:

📄 Datasheet

Description:

3.8ma 10ns switching multiplexers. The AD8180 (single) and AD8182 (dual) are high speed 2-to-1 multiplexers. They offer   –3 dB signal bandwidth greater t

AD8180 Application

• Applications Pixel Switching for “Picture-In-Picture” Switching in LCD and Plasma Displays Video Switchers and Routers PRODUCT DESCRIPTION The AD818
