ADAU1979 Datasheet, Converter, Analog Devices

ADAU1979 Features

• Converter Four 4.5 V rms (typical) differential inputs On-chip phase-locked loop (PLL) for master clock Low electromagnetic interference (EMI) design 109 dB (typical) analog-to-digital converter

PDF File Details

Part number:

ADAU1979

Manufacturer:

Analog Devices ↗

File Size:

2.69MB

Download:

📄 Datasheet

Description:

Quad analog-to-digital converter. The ADAU1979 incorporates four high performance, analog-to-digital converters (ADCs) with 4.5 V rms capable ac-coupled inputs. The AD

ADAU1979 Application

• Applications APPLICATIONS Automotive audio systems Active noise cancellation systems GENERAL DESCRIPTION The ADAU1979 incorporates four high perfor
