ADP5033 Datasheet, Regulators, Analog Devices

ADP5033 Features

• Regulators Main input voltage range: 2.3 V to 5.5 V Two 800 mA buck regulators and two 300 mA LDOs Tiny, 16-ball, 2 mm × 2 mm WLCSP package Regulator accuracy: ±1.8% Factory programmable VOUTx 3 M

PDF File Details

Part number:

ADP5033

Manufacturer:

Analog Devices ↗

File Size:

876.71kb

Download:

📄 Datasheet

Description:

800ma buck regulators. The ADP5033 combines two high performance buck regulators and two low dropout regulators (LDO) in a tiny, 16-ball, 2 mm × 2 mm WLCSP

ADP5033 Application

• Applications Power for processors, ASICS, FPGAs, and RF chipsets Portable instrumentation and medical devices Space constrained devices GENERAL DESC
