ADV7181B Datasheet - Analog Devices

ADV7181B Multiformat SDTV Video Decoder

The ADV7181B integrated video decoder automatically detects and converts a standard analog baseband television signal compatible with worldwide standards NTSC, PAL, and SECAM into 4:2:2 component video data compatible with 16-bit/8-bit CCIR601/CCIR656. The advanced, highly flexible digital output in.

ADV7181B Features

* Multiformat video decoder supports NTSC-(M, J, 4.43), PAL-(B/D/G/H/I/M/N), SECAM Integrates three 54 MHz, 9-bit ADCs Clocked from a single 27 MHz crystal Line-locked clock-compatible (LLC) Adaptive Digital Line Length Tracking (ADLLT™), signal processing, and enhanced FIFO management give mini-TBC f

ADV7181B-AnalogDevices.pdf

Preview of ADV7181B PDF
ADV7181B Datasheet Preview Page 2 ADV7181B Datasheet Preview Page 3

Datasheet Details

Part number:

ADV7181B

Manufacturer:

Analog Devices ↗

File Size:

1.38 MB

Description:

Multiformat sdtv video decoder.
