LTC5552 Datasheet, Mixer, Analog Devices

LTC5552 Features

• Mixer nn Integrated LO Buffer: 0dBm LO Drive nn 50Ω Wideband Matched RF and LO Ports nn Wide IF Bandwidth: DC to 6GHz nn Upconversion or Downconversion nn High IIP3: nn +22.5dBm at 10GHz nn +

PDF File Details

Part number:

LTC5552

Manufacturer:

Analog Devices ↗

File Size:

1.63MB

Download:

📄 Datasheet

Description:

3ghz to 20ghz microwave mixer. The LTC®5552 is a high performance, microwave double balanced passive mixer that can be used for frequency upconversion o

LTC5552 Application

• Applications nn 5G Broadband Wireless Access nn Microwave Transceivers nn Wireless Backhaul nn Point-to-Point Microwave nn Phased-Array Antennas nn
