LTC5551 Datasheet, Mixer, Linear Technology

LTC5551 Features

• Mixer n +36dBm Input IP3 n 2.4dB Conversion Gain n Low Noise Figure: <10dB n +18dBm Ultra High Input P1dB n 670mW Power Consumption n 2.5V to 3.6V Operation n 50Ω Single-Ended RF and LO

PDF File Details

Part number:

LTC5551

Manufacturer:

Linear Technology

File Size:

434.39kb

Download:

📄 Datasheet

Description:

Ultra-high dynamic range downconverting mixer. The LTC®5551 is a 2.5V to 3.6V mixer optimized for RF downconverting mixer applications that require very high dynamic range. The LTC

LTC5551 Application

• Applications n GSM, LTE, LTE-Advanced Basestations n Repeaters n DPD Observation Receiver n Public Safety Radios, Military and Defense n Avioni

TAGS

LTC5551

Linear Technology
