Part number: AIC2802
Manufacturer: Analog Intergrations Corporation
File Size: 194.16KB
Download: 📄 Datasheet
Description: 3A 23V Synchronous PWM Step-Down Converter
* 3A Continuous Output Current
* internal Soft Start
* Up to 90% Efficiency for Heavy Load
(Vin=12V, Vout=3.3V, Iout=3.0A)
* Low Rds(on) Internal Switches.
* Networking Systems
* Distributed Power Systems
* Pre-Regulator for Linear Regulators.
* LCD TV, LCD Mo.
The AIC2802 is a synchronous step-down regulator with an integrated Power MOSFET and extra Power MOSFET to control coutput voltage2. It achieves 3A continuous output current over a wide input supply range with excellent load and line regulation.
Curr.
