ANX3112 - Low Power DisplayPort to LVDS Converter

Product Overview

Analogix

Datasheet Details

Part number	ANX3112
Manufacturer	Analogix
File Size	674.02 KB
Description	Low Power DisplayPort to LVDS Converter
Datasheet	ANX3112 Datasheet
Additional preview pages of the ANX3112 datasheet.

Product details

Description

Low cost DisplayPort™ to LVDS converter with single channel LVDS 18bpp output, 36-pin QFN package Analogix Related Products Part No.ANX3111 ANX1121 ANX3110 ANX1120 ANX9834 ANX9835 ANX9804 ANX9806 ANX9830 ANX9832 Description Low cost DisplayPort™ to LVDS converter with single channel LVDS 18bpp output, 64-pin QFN package Low cost DisplayPort™ to LVDS converter with single channel LVDS 18bpp output, 36-pin QFN package High performance DisplayPort™ 1.1a to dual-LVDS LVDS converter High performa

Features

All software compatible with AMD platform driver/BIOS stacks - Designed and fully tested with extensive APU-based platform test requirements - No additional firmware and EEPROM to manage LCD dimming and video timing control.
Two package options available to support for new and running-change platforms (36 & 64QFN).
Super low power single channel 18-bit per pixel LVDS output - Single channel: Up to 120 MHz pixel clock - 50% power reduction:.
