AZ431-A - ADJUSTABLE PRECISION SHUNT REGULATORS

AZ431-A Description

Product Brief ADJUSTABLE PRECISION SHUNT REGULATORS .
The AZ431-A series ICs are three-terminal adjustable shunt regulators with guaranteed thermal stability over a full operation range.

AZ431-A Features

* Programmable Precise Output Voltage from 2.5V to 36V Very Accurate Reference Voltage: 0.15% Typical High Stability under Capacitive Load Low Temperature Deviation: 4.5mV Typical Low Equivalent Full-range Temperature Coefficient with 20PPM/oC Typi

AZ431-A Applications

* such as switching power supply, charger and other adjustable regulators. The AZ431-A series ICs are of 40V voltage type. Its output voltage can be set to any value between VREF(2.5V) and 36V. The AZ431-A precision reference is offered in two bandgap tolerance: 0.4% and 0.8%. AZ431-A Parametric Tab

📥 Download Datasheet

Preview of AZ431-A PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
AZ431-A
Manufacturer
BCDSEMI
File Size
357.71 KB
Datasheet
AZ431-A_BCDSEMI.pdf
Description
ADJUSTABLE PRECISION SHUNT REGULATORS
