DT5016 SDSL Transformer

SDSL Transformer ★ Designed to meet IR 2350C peak requirement For SMD Parts ★ Excellent THT performance ★ Small EP13 Package in SMD and THT Type Specifications (Operating Temperture Range: -40℃ to +85℃) Part Number Application Turn Ratio (2%) (1-5):(9-7) OCL @ 10 KHz, 0.1 V (1-5), 2-4 shorted with 160mA dc Leakage Inductance (1-5)@ 100 KHz, 0.1 V Insertion Loss @ 40 KHz DT0016 DT5016 SDSL SDSL 3.7:1 3.7:1 2 mH(±6%) 2 mH(±6%) 17uH Max 17uH Max 0.5 dB Max 0.5 dB Max Specifications c.

DT5016 Datasheet (201.64 KB)
