SF-0402S050-2 - Slow Blow Surface Mount Fuses

BOURNS

Datasheet Details

Part number	SF-0402S050-2
Manufacturer	BOURNS
File Size	232.00 KB
Description	Slow Blow Surface Mount Fuses
Datasheet	SF-0402S050-2-BOURNS.pdf

Slow blow thin ﬁlm chip fuse for overcurrent protection.
1005 (EIA 0402) miniature footprint.
Surface mount packaging for automated assembly.
UL 248-14 compliant.
RoHS compliant.
and halogen free.
SF-0402S Series - Slow Blow Surface Mount Fuses Clearing Time Characteristics for Series % of Current Rating 100 % 250 % Clearing Time at 25 °C Min. Max. 4 hours.
5 seconds Additional Information Click these links for more information:.
