Part number: 24WC05J
Manufacturer: Catalyst Semiconductor
File Size: 386.06KB
Download: 📄 Datasheet
Description: CAT24WC05J
s 400 kHz I2C bus compatible* s 1.8 to 5.5 volt operation s Low power CMOS technology s Write protect feature s Self-timed write cycle with auto-clear s 1,000,000 Program.
The CAT24WC03/05 is a 2K/4K-bit Serial CMOS EEPROM internally organized as 256/512 words of 8 bits each. Catalyst’s advanced CMOS technology substantially reduces device power requirements. The
PIN CONFIGURATION
DIP Package (P, L, GL)
A0 A1 A2 VSS 1.
