CTMCA5020

Multi-layer Chip Antennas

CTMCA5020 Features

* Monolithic SMD type. Wide bandwidth Applications: WLAN, Home RF, Bluetooth Modules, etc. Operating Temperature: -40°C to +85°C Input Power: 3 Watts Max. Packaging: Tape & Reel Additional Information: Additional electrical & physical information available upon request Samples available. See website

CTMCA5020 Datasheet (446.04 KB)

Preview of CTMCA5020 PDF

Datasheet Details

Part number:

CTMCA5020

Manufacturer:

Central Technologies

File Size:

446.04 KB

Description:

Multi-layer chip antennas.
Multi-layer Chip Antennas ctparts.com SPECIFICATIONS CTMCA5020 Series Not shown at actual size. Part Number CTMCA5020-2R4 Frequency Range (MHz) 24.
