MX4407A Datasheet, Mosfet, ChipSourceTek

MX4407A Features

  • Mosfet APPLICATION
  • VDS = -30V, ID = -12A
  • PWM applications RDS(ON)(Type)= 9.0mΩ @ VGS=-10V
  • Load switch RDS(ON)(Type)= 12mΩ @ VGS=-4.5V
  • Power manag

PDF File Details

Part number:

MX4407A

Manufacturer:

ChipSourceTek

File Size:

604.55kb

Download:

📄 Datasheet

Description:

P-channel enhancement mode power mosfet. The MX4407A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as

Datasheet Preview: MX4407A 📥 Download PDF (604.55kb)
Page 2 of MX4407A Page 3 of MX4407A

MX4407A Application

  • Applications GENERAL FEATURES APPLICATION
  • VDS = -30V, ID = -12A
  • PWM applications RDS(ON)(Type)= 9.0mΩ @ VGS=-10V
