RY9120 Datasheet, Regulator, ChipSourceTek

RY9120 Features

• Regulator
• Wide 4.5V to 17V Operating Input Range
• 110mΩ/70mΩ Low RDS(ON) Internal Power
• 2A Continuous Output Current MOSFETs
• 500KHz Switching Frequency

PDF File Details

Part number:

RY9120

Manufacturer:

ChipSourceTek

File Size:

1.23MB

Download:

📄 Datasheet

Description:

17v 2a 500khz ecot sync step-down regulator. T The RY9120 is a high frequency, synchronous, rectified, step-down, switch-mode converter with internal power e MOSFETs. It offers

RY9120 Application

• Applications
• Digital Set-top Box (STB)
• Tablet Personal Computer (Pad) k
