MBR3040FCT - SCHOTTKY BARRIER RECTIFIERS

This page provides the datasheet information for the MBR3040FCT, a member of the MBR3020FCT SCHOTTKY BARRIER RECTIFIERS family.

Datasheet Summary

Features

  • Metal-Semiconductor junction with guard ring Epitaxial construction Low forward voltage drop High current capability The plastic material carries UL recognition 94V-0 For use in low voltage,high frequency inverters,free wheeling,and polarity protection.

📥 Download Datasheet

Datasheet preview – MBR3040FCT

Datasheet Details

Part number MBR3040FCT
Manufacturer Compact Technology
File Size 151.03 KB
Description SCHOTTKY BARRIER RECTIFIERS
Datasheet download datasheet MBR3040FCT Datasheet
Additional preview pages of the MBR3040FCT datasheet.

📁 Similar Datasheet

  • MBR3040FCT - SCHOTTKY BARRIER RECTIFIER (JCET)
  • MBR3040FCT - SCHOTTKY BARRIER RECTIFIERS (Pan Jit International)
  • MBR3040FCT - Schottky Barrier Rectifier (MCC)
  • MBR3040FCT - Isolated Schottky Barrier Rectifiers (Microsemi)
  • MBR3040 - Schottky Barrier Rectifier (Micro Commercial Components)
  • MBR3040 - SCHOTTKY BARRIER RECTIFIER (Byte)
  • MBR3040CT - SCHOTTKY BARRIER RECTIFIER (Pan Jit International)
  • MBR3040CT - 30A High Power Schottky Barrier Rectifiers (CITC)
  • MBR3040CT - Schottky Barrier Rectifier (Inchange Semiconductor)
  • MBR3040CT - Schottky Barrier Rectifier (Micro Commercial Components)
Other Datasheets by Compact Technology

Full PDF Text Transcription

Click to expand full text
SCHOTTKY BARRIER RECTIFIERS MBR3020FCT thru MBR30200FCT REVERSE VOLTAGE - 20 to 200 Volts FORWARD CURRENT - 30.0 Amperes FEATURES Metal-Semiconductor junction with guard ring Epitaxial construction Low forward voltage drop High current capability The plastic material carries UL recognition 94V-0 For use in low voltage,high frequency inverters,free wheeling,and polarity protection applications ITO-220AB MECHANICAL DATA Case : ITO-220AB molded plastic Polarity : Color band denotes cathode Weight : 1.689 grams Mounting position : Any Dimensions in inches and (millimeters) MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS Ratings at 25̺ ambient temperature unless otherwise specified. Single phase, half wave, 60Hz, resistive or inductive load.
