S16C20C Datasheet, Rectifiers, Compact Technology

S16C20C Features

• Rectifiers Metal-Semiconductor junction with guard ring Epitaxial construction Low forward voltage drop High current capability The plastic material carries UL recognition 94V-0 For use in low vol

PDF File Details

Part number:

S16C20C

Manufacturer:

Compact Technology

File Size:

180.50kb

Download:

📄 Datasheet

Description:

Schottky barrier rectifiers.

S16C20C Application

• Applications MECHANICAL DATA Case : TO-220AB molded plastic Polarity : Color band denotes cathode Weight : 1.948 grams Mounting position : Any .129
