DS1402D-041

iButton Probe Component Parts

DS1402D-041 Features

* Spring-Mounted iButton Reader Momentary Contact for Both F3 and F5 Style iButtons or Dwelled Contact for F5 Only Convenient Tactile Feedback System for Dwelled iButton Contact ® Mounting Pad Layout .82in Ground .080in Data .46in General Description The four component parts t

DS1402D-041 General Description

The four component parts that are used to construct the Blue-Dotä iButton reader found in the DS1402D-DR8 and DS1402D-DB8 are described here. Diagrams 1 through 4 show the individual part dimensions. This document also describes how to assemble the Blue-Dot given the sub-parts listed in Table 1. The.
