DTU30N02 Datasheet, Mosfet, Din-Tek

DTU30N02 Features

• Mosfet
• Halogen-free According to IEC 61249-2-21 Definition
• TrenchFET® Gen III Power MOSFET
• 100 % Rg Tested
• 100 % UIS Tested
• Compliant to RoHS

PDF File Details

Part number:

DTU30N02

Manufacturer:

Din-Tek

File Size:

281.65kb

Download:

📄 Datasheet

Description:

N-channel mosfet.

DTU30N02 Application

• Applications
• DC/DC
• Low Voltage Drive
• POL G G D S S N-Channel MOSFET Top View ABSOLUTE MAXIMUM RATINGS TA = 25 °
