AH1751

HALL EFFECT LATCH

Diodes Incorporated

AH1751 Features

* Bipolar Hall Effect Latch Sensor

* 3.5V to 20V DC Operation Voltage

* Open Collector Pre-Driver

* 50mA Output Sink Current

* Chip Power Reverse-Connection Protection

* Operating Temperature: -40°C to 125°C

* SIP3, SC59 and SC59R (Commonly known as SOT23 in Asia): Availa

AH1751 General Description

AH1751 is a single-digital-output Hall-effect sensor for high temperature operation. The device includes an on-chip Hall voltage generator for magnetic sensing, an amplifier to amplify Hall voltage, and a comparator to provide switching hysteresis for noise rejection, and an open-collector output pr.

AH1751 Datasheet (393.34 KB)

AH1751 Datasheet Preview — Preview of AH1751 PDF

Datasheet Details

Part number:

AH1751

Manufacturer:

DIODES ↗ Incorporated

File Size:

393.34 KB

Description:

Hall effect latch.
